功能特點/Features
●鋁面板，配有輸出電壓、電流實時顯示。
●后板配有大功率白色LED照明（同時按1、2鍵），方便工程所需。
●有空氣開關保護，遇到短路，過流現象自動斷開電源。
●具有密碼鎖（同時按1、3、5鍵），防止誤觸。
●共10路可控8路電源輸出，每路可達30A。
●可控輸出延時時間為1S。
●USB接口無限級聯機使用。
●Aluminum panel with real-time display of output voltage and current.
●The rear panel is equipped with high-power white LED lighting (press the 1, 2 keys at the same time), which is convenient for the project.
●With air switch protection, it will automatically cut off the power supply in case of short circuit or over current.
●With code lock (press 1, 3, 5 keys at the same time) to prevent accidental touch.
●A total of 10 controllable 8 power outputs, each of which can reach 30A.
●The controllable output delay time is 1S.
●USB interface for unlimited online use.
技術參數/Technlcal Parameters
| 型號 | AC-308 |
| 額定輸出電壓 | 交流220V，50Hz |
| 額定輸出電流 | 25A |
| 可控電源 | 8路 |
| 每路動作延時時間 | 2秒 |
| 供電電源 | VAC50/60Hz 25A
|
應用場所/Application place
演出設備電控/樂隊設備電控/KTV設備電控/娛樂場電控/會議室電控/家庭電控
Performance equipment electric control/band equipment electric control/KTV equipment electric control/casino electric control/conference room electric control/home electric control
